Tubi spiralati per ventilazione ed aspirazione TERMOVEN/150 SPC con spirale coperta
    Tubi spiralati per ventilazione ed aspirazione TERMOVEN/150 SPC con spirale coperta

TERMOVEN/150 SPC

Black color, flexible hose made of two layers of glass fiber impregnated with neoprene rubber incorporating a galvanized steel spiral and an external glass fiber string. For cold and hot air and for exhaust gases suction and delivery. Can be axially compressed up to 30% of the length. Temperature range: -50°C +150°C (max. point). Other internal diameters of production: 19 - 22 - 25 - 26 - 28 - 30 - 32 - 35 - 38 - 39 - 41 - 42 - 44 - 45 - 52 - 55 - 57 - 58 - 60 - 62 - 64 - 65 - 67 - 70 - 72 - 80 - 83 - 92 - 95 - 108 - 110 - 114 - 120 - 130 - 140 - 160 - 165 - 170 - 178 - 180 - 229. Flame retardant regulation: UL 94 V-1. Other sizes and versions available on request: with end cuffs, insulated or in UL 94 V-0 class.

Technical Data
Information request

Technical Data

Description Suction mm/H₂O Weight g/m Working press. bar Bending radius mm Packaging
TUBO P TERMOVEN/150°C./NERO 51 SPC 5100 360 2,6 24 4 MT
TUBO P TERMOVEN/150°C./NERO 63 SPC 4500 485 2,4 31 4 MT
TUBO P TERMOVEN/150°C./NERO 76 SPC 4200 580 2,2 38 4 MT
TUBO P TERMOVEN/150°C./NERO 89 SPC 3900 690 2 44 4 MT
TUBO P TERMOVEN/150°C./NERO 102 SPC 3400 770 1,9 52 4 MT
TUBO P TERMOVEN/150°C./NERO 127 SPC 2300 925 1,4 69 4 MT
TUBO P TERMOVEN/150°C./NERO 152 SPC 1600 1200 1,2 75 4 MT
TUBO P TERMOVEN/150°C./NERO 203 SPC 850 1650 0,7 101 4 MT
TUBO P TERMOVEN/150°C./NERO 254 SPC 650 2090 0,5 150 4 MT
TUBO P TERMOVEN/150°C./NERO 305 SPC 450 2550 0,3 200 4 MT

Application Sectors
