MANICHETTA PADOVA/M - LAYFLAT

Layflat PVC mono-extruded hose with polyester reinforcement. Blue color. For water delivery in agriculture, building sites and industry. Safety factor: 1÷3. Temperature range: -10°C +65°C.

Technical Data
Information request

Technical Data

Description Weight g/m Working press. bar Thickness mm Centering and thickness tolerances Packaging
MANICHETTA PADOVA 30/32 M. 170 8 1,3 10% 50 MT
MANICHETTA PADOVA 60/63 M. 420 6 1,6 20% 50 MT
MANICHETTA PADOVA 50/52 M. 320 6 1,5 10% 50 MT
MANICHETTA PADOVA 35 M. 200 8 1,3 10% 50 MT
MANICHETTA PADOVA 40 M. 250 8 1,4 10% 50 MT
MANICHETTA PADOVA 76 M. 500 6 1,5 20% 50 MT
MANICHETTA PADOVA 80 M. 650 6 1,8 20% 50 MT
MANICHETTA PADOVA 102 M. 750 6 2,0 20% 50 MT
MANICHETTA PADOVA 127 M. 1000 5 1,9 20% 50 MT
MANICHETTA PADOVA 150 M. RACC.DA MT.20 RACC.ZINC. M72ANF +F73ANF FASC
MANICHETTA PADOVA 152 M. 1200 4 2,0 20% 50 MT
MANICHETTA PADOVA 203 M. 2300 4 2,8 20% 50 MT
MANICHETTA PADOVA 254 M. 2600 3 2,5 20% 30 MT
MANICHETTA PADOVA 305 M. 3000 3 2,4 20% 30 MT
